Characteristics
Solenoid valve consumption: 9 WFuel consumption: 24 l/hReturn pressure: 2 barTorque: 0.1 N·mStrainer: Open area: 11 cm²Strainer: Opening size: 200 µmFactory pressure setting: 10 barShaft diameter: 8 mmInlet pressure: 2 barDirection of rotation (looking at the drive shaft): L: counterclockwise rotationSolenoid valve voltage: 220-240V~, 50-60HzVacuum gauge port: ⅛ inchPressure gauge port: ⅛ inchSuction and return line: ¼ inchMaximum rotation speed: 3,450 rpmConnection type: G 1/4"Operating viscosity: from 1.3 to 12 mm²/sInstallation method: sleeve ⌀32 mmDegree of protection: IP40Type of pumped liquid: gasoline, keroseneNominal rotation speed: 2,400 rpm
Information about the technical characteristics, appearance and color of the product is for reference only and is based on the latest information available at the time of publication
