Characteristics
Manufacturer Part Number: 0120050Fuel consumption: 1,200 l/hInlet pressure: 5 barShaft diameter: 22 mmReturn pressure: 10 barTorque: 4.6 N·mFactory pressure setting: 15 barNominal rotation speed: 1,400 rpmOperating viscosity: from 3.6 to 1,150 mm²/sVacuum gauge port: ¼ inch NPTFPressure gauge port: ¼ inchOil temperature: from 0 to 150 °C in the pumpNozzle pressure range: from 15 to 40 barSuction height: 0.45 bars max. vacuum to prevent air separation from oilType of pumped liquid: diesel, sea water, keroseneNozzle outlet: ⅜ inchSuction and return line: 1 inchDirection of rotation (looking at the drive shaft): D: clockwise rotation
Information about the technical characteristics, appearance and color of the product is for reference only and is based on the latest information available at the time of publication
